• On-site measuring, in-time reading
  • 4 modes available to cover all facets
  • Continuous monitor and nothing can vanish from your sight
  • Complete storage for your access anytime, anywhere!
  • Touchpad interface, easy and user-friendly even for newcomers
  • Encryption WiFi SD transmission: MK350N WiFi-SD Solution
  • On-site measuring, in-time reading
  • 4 modes available to cover all facets
  • Continuous monitor and nothing can vanish from your sight
  • Complete storage for your access anytime, anywhere!
  • Touchpad interface, easy and user-friendly even for newcomers
    MK350N Spectrometer
  Sensor CMOS Linear Image
Sensor
  Resolution 12 nm
  Wavelength Range 360 ~ 750 nm
  Measurement Range 70 ~ 70000 Lux
  Cosine Recipt Area 6.6 ± 0.1 mm
  Exposure Time Range 8 ~ 1000 ms
  Capture Mode Once / Continue
  Integrating Mode Auto / Manual
  Measuring Modes 1. Basic Value Mode
2. Spectrum Graph Mode
3. CIE 1931 Chromaticity Dragram Mode
4. CIE 1976 U.C.S Chromaticity Dragram Mode
  Measuring Capabilities 1. Spectral Irradiance
2. C.I.E. Chromaticity Coordinates
    (1) CIE 1931 x,y Coordinates
    (2) CIE 1976 U.C.S u',v' Coordinates
3. Peak Wavelength
4. Correlated Color Temperature; CCT ( in Kelvins)
5. Color Rendering Index; Ra ( Rendering Average )
6. Illuminance / Lux
  Digital Resolution 16 bits
  Dark Calibration Yes
  Stray Light -25 dB max.
( When monochromatic light of the 550nm wavelength is input, spectral stray
light is defined as the ratio of count measured at the input wavelength, to the
measured in a region of the input wavelength ± 40nm. )
  Wavelength Data
Increment		 1 nm
  Wavelength
Reproducibility		 ± 1 nm
( Measured under constant light input conditions )
  Illuminance Accuracy ± 5% Illuminant A @ 2856k at 20000 lux
  Color Accuracy ± 0.0025 in CIE 1931 x,y
  Color Repeatability ± 0.0005 in CIE 1931 x,y
  CCT Accuracy ± 2%
  CRI Accuracy @ Ra ± 1.5%
  Display 3.5" LCD 320X240 Touch Panel
  Battery Operation Time ≦ 5 hours / One Full Charge
  Battery 2500 mAh / Reachargeable Li-ion Battery
  Date Output Interface SD Card / USB 2.0
  Data Format Compatible MicroSoft Office Excel Data Format & BMP Format
  Dimensions 144.2 x 78 x 24 mm ( H x W x D )
  Weight ( with Battery ) 250 g ± 20 g
  Operating Temperature
Range		 0 ~ 35 °C
  Storage Temperature
Range		 -10 ~ 40 °C
  Language English, Japanese, Simplified Chinese, Traditional Chinese
  Place of Origin Taiwan
  Certification CE
MK350N
